How to remove and install the camshaft position sensor in Hyundai Santa Fe?

For 2.4L four-cylinder models, the sensor is located on the driver's end of the cylinder head for 2007 and earlier engines, while 2010 and later models have two sensors on each side of the valve cover towards the driver's end. Begin by disconnecting the cable from the negative battery terminal, then remove the air intake duct if necessary for better access. Disconnect the electrical connector from the CMP sensor(s) and make an alignment mark with a dab of paint for reinstallation. Remove the CMP sensor(s) mounting bolt(s) and the sensor(s), checking the O-ring condition if reinstalling the same sensor, replacing it if damaged. Installation follows the reverse order. For 2.7L and 3.3L V6 models, the camshaft position sensor is mounted on the driver's end of the cylinder head. Start by disconnecting the negative battery terminal, then remove the engine cover if needed for access. Disconnect the sensor electrical connector, remove the bolt securing the sensor to the cylinder head, and pull the sensor out. Installation is the reverse of removal. For 3.5L V6 models, the sensor is mounted under the timing belt cover near the exhaust camshaft sprocket for 2007 and earlier models, while 2010 and later engines have four sensors, two on each valve cover. Disconnect the negative battery terminal, remove the timing belt cover for 2007 and earlier models to access the sensor, or remove the engine cover for 2010 and later models. Disconnect the sensor electrical connector, remove the sensor mounting bolt(s), and installation is the reverse of removal.

Genuine Hyundai Santa Fe Camshaft Position Sensor

Cam Position Sensor

Select Vehicle by Model
Select Vehicle by VIN

Select Vehicle by Model

Make

Model

Year

Select Vehicle by VIN

For the most accurate results, select vehicle by your VIN (Vehicle Identification Number).

12 Camshaft Position Sensors found

View related parts
Hyundai Santa Fe Sensor-Camshaft Position
Part Number: 39350-25010
$130.37 MSRP: $183.16
You Save: $52.79 (29%)
Ships in 1-3 Business Days
ADD TO CART
Product Specifications
- Other Name: Camshaft Position Sensor, Camshaft Sensor
- Replaces: 39350-25000
- Warranty: This genuine part is guaranteed by Hyundai's factory warranty.
Fits the following Vehicles:
- 2009-2012 Hyundai Santa Fe | DOHC - MPI | Wagon - 5Door 5P
View related parts
Hyundai Santa Fe Sensor-Camshaft Position
Part Number: 39350-2G000
$68.05 MSRP: $95.61
You Save: $27.56 (29%)
Ships in 1-3 Business Days
ADD TO CART
Product Specifications
- Warranty: This genuine part is guaranteed by Hyundai's factory warranty.
Fits the following Vehicles:
- 2019-2020 Hyundai Santa Fe | DOHC - GDI, DOHC - TCI/GDI | Wagon - 5Door 5P
View related parts
Hyundai Santa Fe Sensor-Camshaft Position
Part Number: 39318-3C500
$120.88 MSRP: $169.84
You Save: $48.96 (29%)
Ships in 1-2 Business Days
ADD TO CART
Product Specifications
- Warranty: This genuine part is guaranteed by Hyundai's factory warranty.
Fits the following Vehicles:
- 2013-2018 Hyundai Santa Fe | DOHC - GDI | Wagon - Long 5Door 6P, Wagon - Long 5Door 7P
View related parts
Hyundai Santa Fe Sensor-Camshaft Position
Part Number: 39318-3C100
$107.26 MSRP: $150.69
You Save: $43.43 (29%)
Ships in 1-2 Business Days
ADD TO CART
Product Specifications
- Other Name: Camshaft Position Sensor, Camshaft Sensor, ECM
- Replaces: 39318-3C300
- Warranty: This genuine part is guaranteed by Hyundai's factory warranty.
Fits the following Vehicles:
- 2006-2012 Hyundai Santa Fe | High Grade, Middle Grade | DOHC - MPI | 5 Door Wagon, 5 Door Wagon 7, Wagon - 5Door 5P, Wagon - 5Door 7P
View related parts
Hyundai Santa Fe Sensor-TDC(Hall)
Part Number: 39350-37110
$198.88 MSRP: $279.42
You Save: $80.54 (29%)
Ships in 1-3 Business Days
ADD TO CART
Product Specifications
- Other Name: Sensor-Top Dead Center(Hall)
- Manufacturer Note: HALL
- Replaces: 39350-37100
- Warranty: This genuine part is guaranteed by Hyundai's factory warranty.
Fits the following Vehicles:
- 2000-2006 Hyundai Santa Fe | High Grade, Middle Grade | 5 Door Wagon
View related parts
Hyundai Santa Fe Sensor-Camshaft Position,LH
Part Number: 39350-3E120
$193.06 MSRP: $271.24
You Save: $78.18 (29%)
Ships in 1-3 Business Days
ADD TO CART
Product Specifications
- Other Name: Camshaft Position Sensor
- Position: Driver Side
- Replaces: 39350-3E220
- Warranty: This genuine part is guaranteed by Hyundai's factory warranty.
Fits the following Vehicles:
- 2006-2009 Hyundai Santa Fe | High Grade, Middle Grade | DOHC - MPI | 5 Door Wagon, 5 Door Wagon 7, Wagon - 5Door 5P, Wagon - 5Door 7P
View related parts
Hyundai Santa Fe Sensor-Camshaft Position
Part Number: 39318-3C510
$118.42 MSRP: $166.37
You Save: $47.95 (29%)
Ships in 1-3 Business Days
ADD TO CART
Product Specifications
- Warranty: This genuine part is guaranteed by Hyundai's factory warranty.
Fits the following Vehicles:
- 2016-2018 Hyundai Santa Fe | DOHC - GDI | Wagon - Long 5Door 6P, Wagon - Long 5Door 7P
View related parts
Hyundai Santa Fe Sensor-Camshaft Position
Part Number: 39318-39150
$188.18 MSRP: $264.39
You Save: $76.21 (29%)
Ships in 1-3 Business Days
ADD TO CART
Product Specifications
- Other Name: Camshaft Position Sensor
- Warranty: This genuine part is guaranteed by Hyundai's factory warranty.
Fits the following Vehicles:
- 2000-2006 Hyundai Santa Fe | High Grade, Middle Grade | 5 Door Wagon
View related parts
Hyundai Santa Fe Sensor-Camshaft Position,RH
Part Number: 39350-3E110
$193.06 MSRP: $271.24
You Save: $78.18 (29%)
Ships in 1-2 Business Days
ADD TO CART
Product Specifications
- Position: Passenger Side
- Warranty: This genuine part is guaranteed by Hyundai's factory warranty.
Fits the following Vehicles:
- 2006-2009 Hyundai Santa Fe | High Grade, Middle Grade | DOHC - MPI | 5 Door Wagon, 5 Door Wagon 7, Wagon - 5Door 5P, Wagon - 5Door 7P
View related parts
Hyundai Santa Fe Sensor-Camshaft Position
Part Number: 39310-38050
$191.65 MSRP: $269.26
You Save: $77.61 (29%)
Ships in 1-3 Business Days
ADD TO CART
Product Specifications
- Other Name: Camshaft Position Sensor
- Warranty: This genuine part is guaranteed by Hyundai's factory warranty.
Fits the following Vehicles:
- 2000-2006 Hyundai Santa Fe | High Grade, Middle Grade | 5 Door Wagon
View related parts
Hyundai Santa Fe Sensor-Camshaft Position
Part Number: 39350-2S000
$34.36 MSRP: $47.85
You Save: $13.49 (29%)
Ships in 1-3 Business Days
ADD TO CART
Product Specifications
- Other Name: Camshaft Position Sensor, Camshaft Sensor
- Warranty: This genuine part is guaranteed by Hyundai's factory warranty.
Fits the following Vehicles:
- 2021-2023 Hyundai Santa Fe | DOHC - GDI, DOHC - TCI/GDI | Wagon - 5Door 5P
View related parts
Hyundai Santa Fe Sensor Assembly-TDC(Hall)
Part Number: 39305-37100
Product Specifications
- Other Name: Sensor Assembly-Top Dead Center(Hall); TDC Sensor
- Warranty: This genuine part is guaranteed by Hyundai's factory warranty.
Fits the following Vehicles:
- 2000-2006 Hyundai Santa Fe | High Grade, Middle Grade | 5 Door Wagon

Hyundai Santa Fe Camshaft Position Sensor

The Hyundai Santa Fe Camshaft Position Sensor acts as the engine's timekeeper, reading the camshaft speed and position and then feeding the camshaft position numbers to the engine control module, which is responsible for fuel injection and spark to hit each cylinder in the right order and keep the vehicle from stalling. Though tiny, this Camshaft Position Sensor occupies space above the camshaft in many Hyundai engines, while other Santa Fe editions tuck the device behind the cylinder head or near the block. In all locations, it is doing the same thing, reporting on its position very quickly to keep sequential injectors in sync. Early Santa Fe models and newer trims alike depend on a magnetic Hall-effect style Camshaft Position Sensor that works in tandem with the crank sensor to line up the piston and valve movement to smooth starts and accurate reading of RPM values, but installation location is the primary variation drivers will notice. If the Camshaft Position Sensor fails, misfires, hard starts, or sudden shutdowns can manifest, so there is something to be gained by Hyundai owners replacing it quickly to keep the dependable rhythm that gives every Santa Fe its confident pull. Regular checks of the Camshaft Position Sensor on any Hyundai extend the life of the engine.

If you are looking for affordable high-quality OEM Hyundai Santa Fe Camshaft Position Sensor, then you have come to the prime place. Our website provides a large amount of genuine Hyundai Santa Fe Camshaft Position Sensor at unbeatable prices. All our parts come backed with the manufacturer's warranty.

Hyundai Santa Fe Camshaft Position Sensor Parts Questions & Experts Answers

Sensor-Camshaft Position
39318-3C100
Q: How to remove and install the camshaft position sensor in Hyundai Santa Fe?
A:
For 2.4L four-cylinder models, the sensor is located on the driver's end of the cylinder head for 2007 and earlier engines, while 2010 and later models have two sensors on each side of the valve cover towards the driver's end. Begin by disconnecting the cable from the negative battery terminal, then remove the air intake duct if necessary for better access. Disconnect the electrical connector from the CMP sensor(s) and make an alignment mark with a dab of paint for reinstallation. Remove the CMP sensor(s) mounting bolt(s) and the sensor(s), checking the O-ring condition if reinstalling the same sensor, replacing it if damaged. Installation follows the reverse order. For 2.7L and 3.3L V6 models, the camshaft position sensor is mounted on the driver's end of the cylinder head. Start by disconnecting the negative battery terminal, then remove the engine cover if needed for access. Disconnect the sensor electrical connector, remove the bolt securing the sensor to the cylinder head, and pull the sensor out. Installation is the reverse of removal. For 3.5L V6 models, the sensor is mounted under the timing belt cover near the exhaust camshaft sprocket for 2007 and earlier models, while 2010 and later engines have four sensors, two on each valve cover. Disconnect the negative battery terminal, remove the timing belt cover for 2007 and earlier models to access the sensor, or remove the engine cover for 2010 and later models. Disconnect the sensor electrical connector, remove the sensor mounting bolt(s), and installation is the reverse of removal.
