How to remove and install the Crankshaft Position Sensor on Hyundai Santa Fe?

For 2007 and earlier 2.4L four-cylinder and 3.5L V6 models, the CKP sensor is located on the front of the engine, behind the timing belt cover, next to the crankshaft sprocket. Begin by disconnecting the cable from the negative battery terminal, then remove the lower timing belt cover. Next, disconnect the sensor wiring harness, remove the two mounting bolts, and lift the sensor off, with installation being the reverse of removal. For 2010 and later models, including 2.4L four-cylinder, 2.7L V6, 3.3L V6, and 3.5L V6, the CKP sensor is mounted on the side of the engine block near the bell housing. Disconnect the sensor wiring harness, remove the CKP sensor mounting bolt, and take out the CKP sensor. For 2.4L models, remove the cover plate fasteners and plate to access the sensor mounting bolt, with installation again being the reverse of removal.

Genuine Hyundai Santa Fe Crankshaft Position Sensor

Engine Crankshaft Position Sensor

Select Vehicle by Model
Select Vehicle by VIN

Select Vehicle by Model

Make

Model

Year

Select Vehicle by VIN

For the most accurate results, select vehicle by your VIN (Vehicle Identification Number).

13 Crankshaft Position Sensors found

View related parts
Hyundai Santa Fe Crankshaft Position Sensor
Part Number: 39180-25300
$181.01 MSRP: $254.31
You Save: $73.30 (29%)
Ships in 1-3 Business Days
ADD TO CART
Product Specifications
- Other Name: Sensor-Crankshaft Position; Crankshaft Position Sensor, Crankshaft Sensor
- Replaces: 39180-25200
- Warranty: This genuine part is guaranteed by Hyundai's factory warranty.
Fits the following Vehicles:
- 2009-2012 Hyundai Santa Fe | DOHC - MPI | Wagon - 5Door 5P
View related parts
Hyundai Santa Fe Sensor-Crankshaft Angle
Part Number: 39310-3C100
$130.26 MSRP: $183.02
You Save: $52.76 (29%)
Ships in 1-3 Business Days
ADD TO CART
Product Specifications
- Replaces: 39310-3C200
- Warranty: This genuine part is guaranteed by Hyundai's factory warranty.
Fits the following Vehicles:
- 2006-2009 Hyundai Santa Fe | High Grade, Middle Grade | DOHC - MPI | 5 Door Wagon, 5 Door Wagon 7, Wagon - 5Door 5P, Wagon - 5Door 7P
View related parts
Hyundai Santa Fe Crankshaft Position Sensor
Part Number: 39180-2G000
$145.05 MSRP: $203.79
You Save: $58.74 (29%)
Ships in 1-3 Business Days
ADD TO CART
Product Specifications
- Other Name: Sensor-Crankshaft Position; Crankshaft Position Sensor, Crankshaft Sensor
- Warranty: This genuine part is guaranteed by Hyundai's factory warranty.
Fits the following Vehicles:
- 2019-2020 Hyundai Santa Fe | DOHC - GDI, DOHC - TCI/GDI | Wagon - 5Door 5P
View related parts
Hyundai Santa Fe Sensor-Crankshaft Angle
Part Number: 39310-3C410
$85.69 MSRP: $120.39
You Save: $34.70 (29%)
Ships in 1-3 Business Days
ADD TO CART
Product Specifications
- Other Name: Crankshaft Position Sensor, Crankshaft Sensor
- Warranty: This genuine part is guaranteed by Hyundai's factory warranty.
Fits the following Vehicles:
- 2009-2012 Hyundai Santa Fe | DOHC - MPI | Wagon - 5Door 5P
View related parts
Hyundai Santa Fe Sensor-Crankshaft Angle
Part Number: 39310-3C600
$83.92 MSRP: $117.90
You Save: $33.98 (29%)
Ships in 1-3 Business Days
ADD TO CART
Product Specifications
- Other Name: Crankshaft Position Sensor, Crankshaft Sensor
- Warranty: This genuine part is guaranteed by Hyundai's factory warranty.
Fits the following Vehicles:
- 2013-2018 Hyundai Santa Fe | DOHC - GDI | Wagon - Long 5Door 6P, Wagon - Long 5Door 7P
View related parts
Hyundai Santa Fe Crankshaft Position Sensor
Part Number: 39180-3E100
$170.86 MSRP: $240.05
You Save: $69.19 (29%)
Ships in 1-3 Business Days
ADD TO CART
Product Specifications
- Other Name: Sensor-Crankshaft Position; Crankshaft Position Sensor
- Warranty: This genuine part is guaranteed by Hyundai's factory warranty.
Fits the following Vehicles:
- 2006-2009 Hyundai Santa Fe | High Grade, Middle Grade | DOHC - MPI | 5 Door Wagon, 5 Door Wagon 7, Wagon - 5Door 5P, Wagon - 5Door 7P
View related parts
Hyundai Santa Fe Harness-Ignition Coil
Part Number: 39610-3C500
$95.38 MSRP: $134.00
You Save: $38.62 (29%)
Ships in 1-3 Business Days
ADD TO CART
Product Specifications
- Other Name: Harness, Wire Harness
- Replaces: 39610-3C020
- Warranty: This genuine part is guaranteed by Hyundai's factory warranty.
Fits the following Vehicles:
- 2009-2018 Hyundai Santa Fe | DOHC - GDI, DOHC - MPI | Wagon - 5Door 5P, Wagon - Long 5Door 6P, Wagon - Long 5Door 7P
View related parts
Hyundai Santa Fe Sensor-Crankshaft Angle
Part Number: 39310-39050
$199.01 MSRP: $279.60
You Save: $80.59 (29%)
Ships in 1-3 Business Days
ADD TO CART
Product Specifications
- Other Name: Crankshaft Position Sensor
- Warranty: This genuine part is guaranteed by Hyundai's factory warranty.
Fits the following Vehicles:
- 2000-2006 Hyundai Santa Fe | High Grade, Middle Grade | 5 Door Wagon
View related parts
Hyundai Santa Fe Crankshaft Position Sensor
Part Number: 39180-2S000
$59.99 MSRP: $84.29
You Save: $24.30 (29%)
Ships in 1-3 Business Days
ADD TO CART
Product Specifications
- Other Name: Sensor-Crankshaft Position; Crankshaft Position Sensor, Crankshaft Sensor
- Warranty: This genuine part is guaranteed by Hyundai's factory warranty.
Fits the following Vehicles:
- 2021-2023 Hyundai Santa Fe | DOHC - GDI | Wagon - 5Door 5P
View related parts
Hyundai Santa Fe Crankshaft Position Sensor
Part Number: 39180-2S200
$54.54 MSRP: $75.97
You Save: $21.43 (29%)
Ships in 1-3 Business Days
ADD TO CART
Product Specifications
- Other Name: Sensor-Crankshaft Position; Crankshaft Position Sensor, Crankshaft Sensor
- Warranty: This genuine part is guaranteed by Hyundai's factory warranty.
Fits the following Vehicles:
- 2021-2023 Hyundai Santa Fe | DOHC - TCI/GDI | Wagon - 5Door 5P
View related parts
Hyundai Santa Fe Crankshaft Position Sensor
Part Number: 39180-37150
Product Specifications
- Other Name: Sensor-Crankshaft Position; Crankshaft Position Sensor, Crankshaft Sensor
- Manufacturer Note: SIEMENS
- Replaces: 39180-37200
- Warranty: This genuine part is guaranteed by Hyundai's factory warranty.
Fits the following Vehicles:
- 2000-2006 Hyundai Santa Fe | High Grade, Middle Grade | 5 Door Wagon
View related parts
Hyundai Santa Fe Sensor-Crankshaft Angle
Part Number: 39310-38070
Product Specifications
- Other Name: Crankshaft Position Sensor
- Warranty: This genuine part is guaranteed by Hyundai's factory warranty.
Fits the following Vehicles:
- 2000-2006 Hyundai Santa Fe | High Grade, Middle Grade | 5 Door Wagon
View related parts
Hyundai Santa Fe Sensor-CRANKSHAFT An
Part Number: 39310-3C400
Product Specifications
- Other Name: Sensor-Crankshaft Angle
- Warranty: This genuine part is guaranteed by Hyundai's factory warranty.
Fits the following Vehicles:
- 2009-2010 Hyundai Santa Fe | DOHC - MPI | Wagon - 5Door 5P

Hyundai Santa Fe Crankshaft Position Sensor

The Hyundai Santa Fe Crankshaft Position Sensor continuously tracks crankshaft angle and speed so the engine computer can fire spark and inject fuel at precisely the right moments. Placed near the pulley or flywheel, this Crankshaft Position Sensor sends rapid electrical pulses that the powertrain control module converts into engine RPM and phase data, letting variable valve timing and start up sequences stay synchronized. Without a healthy Crankshaft Position Sensor the ECU guesses, wasting fuel. Over the years, Hyundai Santa Fe models have employed four main styles of Crankshaft Position Sensor, namely inductive, Hall effect, magnetoresistive and optical versions. Inductive units create a voltage as metal teeth pass the sensor, while Hall and magnetoresistive designs react to magnetic field changes and can read the crank even when it sits still, giving newer Hyundai engines faster starts and steadier idle. Optical sensors use a light beam and slotted wheel for the sharp edge detection yet can foul if dirt blocks the beam. Heat, vibration or corrosion can degrade any Santa Fe sensor causing misfires, stalling or a no start until the failing Crankshaft Position Sensor is replaced, and modern sealed housings now help protect the Hyundai component for Santa Fe reliability.

If you are looking for affordable high-quality OEM Hyundai Santa Fe Crankshaft Position Sensor, then you have come to the prime place. Our website provides a large amount of genuine Hyundai Santa Fe Crankshaft Position Sensor at unbeatable prices. All our parts come backed with the manufacturer's warranty.

Hyundai Santa Fe Crankshaft Position Sensor Parts Questions & Experts Answers

Crankshaft Position Sensor
39180-37150
Q: How to remove and install the Crankshaft Position Sensor on Hyundai Santa Fe?
A:
For 2007 and earlier 2.4L four-cylinder and 3.5L V6 models, the CKP sensor is located on the front of the engine, behind the timing belt cover, next to the crankshaft sprocket. Begin by disconnecting the cable from the negative battery terminal, then remove the lower timing belt cover. Next, disconnect the sensor wiring harness, remove the two mounting bolts, and lift the sensor off, with installation being the reverse of removal. For 2010 and later models, including 2.4L four-cylinder, 2.7L V6, 3.3L V6, and 3.5L V6, the CKP sensor is mounted on the side of the engine block near the bell housing. Disconnect the sensor wiring harness, remove the CKP sensor mounting bolt, and take out the CKP sensor. For 2.4L models, remove the cover plate fasteners and plate to access the sensor mounting bolt, with installation again being the reverse of removal.
